Contour

CAD drafting Contour 0    Ribbon: Raster – Filters > CAD software Contour 1 4 Connected Contour

CAD drawing Contour 2    Ribbon: Raster – Filters > CAD drafting Contour 3 8 Connected Contour

CAD software Contour 4    Menu: Raster – Filters – Contour > CAD drawing Contour 5 4-coupling

CAD drafting Contour 6    Menu: Raster – Filters – Contour > CAD software Contour 7 8-coupling

CAD drawing Contour 8 Command line: CONTOUR4

CAD drafting Contour 9 Command line: CONTOUR8

CAD software Contour 10   This functionality is available only in the Raster module.

Contour filters turn filled raster areas into single-pixel contours. In a four-connected contour, adjacent pixels can only be joined by the sides, in an eight-connected contour, contiguity is also allowed at the corners, so such contours look thinner.

The images below show the results of applying contour filters.

CAD drawing Contour 11

Parts of contours obtained with four-connected and eight-connected filtering

Select the images to be processed and run the command.
