New in Construction

Expand All Collapse All

Version 22

New Features of Fasteners

The properties of fastener parts have been worked out.
For old standards, the following properties have been added:

Thread direction
Thread tolerance field
Material
Strength class/group
Type/grade of steel
Coating
Coating thickness

For new standards, the following properties have been added:

Material
Strength class
Coating
Coating element
Coating thickness
Finishing of the coating
Coating method
Coating lubrication
Duration of trials

Other improvements

The hangup when adding templates to the Library of templates for elements of utilities network has been fixed.
The work of the report and the name of the wall templates if they are absent in the database of elements has been fixed.
The configuration error in settings of Construction axis and Separate axis dialogs have been corrected.
The wall thickness overlapping with the background when inserting a wall template with layers into a drawing has been fixed.

Version 21

Volume calculations of wall materials

Automatic specifications

Automatic specifications of materials for selected walls are implemented.

New report generation options

New report generation options are added to the interior composition list:

Areas of premises with the same cladding can now be summed or kept separate
Premise numbers and names can now be placed in separate columns
